HT-WLBL Watchlog Bluetooth-Plus Hydrostatic Level Sensors

Product Description
Watchlog Bluetooth-Plus sensors send level readings straight to your mobile device or tablet, making multi-channel wireless level monitoring affordable for small-scale applications. Readings can be transmitted at rates of 100ms up to 10s over distances of up to 90m.
The hydrostatic level sensor is available with pressure ranges from 0...0.15 mH20 up to 0...3 mH20 and cable lengths from 1.5m up to 4m, with other pressure ranges and cable lengths are available on request.
Features
- Multi-channel wireless level monitoring
- Mobile device connectivity
- Configurable transmission rates
- Up to 90m transmission distance
- Various cable lengths available
- Custom pressure ranges on request
Order Information
Order Code
WLBL-XXXX-Z.ZReplace XXXX with level range and Z.Z with cable length.
Level range
| Level range | *Replace XXXX with |
|---|---|
| 0...0.15 mH20 | 0015 |
| 0...0.3 mH20 | 0030 |
| 0...0.6 mH20 | 0060 |
| 0...1.5 mH20 | 0150 |
| 0...3 mH20 | 0300 |
Cable length
| Cable length | *Replace XXXX with |
|---|---|
| 1.5m | 1.5 |
| 2m | 2.0 |
| 3m | 3.0 |
| 4m | 4.0 |
